| Unit of measurement | Iso-Mix EC 315 FR1 | |
| Connected air duct size | mm | 315 |
| Phases | - | 1 |
| Minimum supply voltage | V | 230 |
| Maximum supply voltage | V | 230 |
| Power supply frequency | Hz | 50/60 |
| Rated power | W | 284 |
| Unit current | A | 1.25 |
| Maximum airflow | m³/h | 1970 |
| Sound pressure level LpA at 3 m | dB(A) | 46 |
| Weight | kg | 19.8 |
| Transported air temperature (max) | °С | 55 |
| Transported air temperature (min) | °С | -25 |
| Ingress protection rating | - | IPX4 |
| Impeller material | - | Plastic |
| Trademark | Blauberg |
| Model | Iso-Mix EC 315 FR1 |
| Type of ventilation unit | Unidirectional |
| Type of drive installed | Integrated VSD |
| Type of heat recovery system | None |
| Nominal external pressure (Pa) | 371 |
| Maximum external leakage rates (%) | 2.7 |
| Static efficiency (%) | 46.6 |
| Declared typology | NRVU UVU |
| Effective electric power input (kW) | 0.283 |
| Sound power level (dB(A)) | 66 |
| ØD | H | L | L1 | W | W1 |
|---|---|---|---|---|---|
| 313 | 434 | 785 | 180 | 526 | 450 |
| Name | Photo | Description |
|---|---|---|
| Blauberg CDT E/0-10 |
|
Speed control for EC motors |
